Weidmuller 1479780000 – Introducing TERMSERIES, the ultimate all-rounders in a convenient terminal block format. These relay modules and solid-state relays are versatile additions to the Klippon® Relay portfolio, offering quick and easy exchangeability and making them ideal for modular systems. With their illuminated ejection lever, which doubles as a status LED and marker holder, maintenance becomes effortless. The TERMSERIES products are designed to save space and are available in widths as slim as 6.4 mm. In addition to their versatility, they offer a wide range of accessories and unlimited cross-connection possibilities. With options for 1 and 2 CO contacts, 1 NO contact, and a unique multi-voltage input ranging from 24 to 230 V UC, TERMSERIES relays cater to diverse application needs. Input voltages from 5 V DC to 230 V UC are color-coded for easy identification (red for AC, blue for DC, and white for UC). Some variants even feature a convenient test button. The high-quality design ensures safety during installation with no sharp edges, minimizing the risk of injuries. Partition plates are also available for optical separation and reinforced insulation. When it comes to reliability, flexibility, and ease of use, TERMSERIES is the go-to choice for your terminal block relay requirements.
Relay Mounting
Din Rail
Relay Connection Type
Screw Connection
Coil Voltage Rating
24 VDC
Relay Contact Material
Agsno
Relay Poles
Single Pole
Relay Throws
Single Throw Normally Open
Relay Input Amperage
16 Amp
Manufacturer
Weidmuller
Component
Electromechanical Relay
Relay Indication
Green LED
